RGBlink DXP H0104 Distributor HDMI 1 Input 4 Output Video Matrix Splitter

RGBlink DXP H0104 is a HDMI2.0 one HDMI input and four HDMI outputs video distributor, to achieve 1 x HDMI2.0 input and 4 x HDMI2.0 output signals distribution. HDMI2.0 supports HDR Ycbcr:4:4:4 technology and 4Kx2K /60Hz resolution, HDCP2.2, 8 bits /10 bits /12 bits /36 bits /36 bits deep color. It supports input EDID management with two EDID modes, users can set according to the needs of the application, complete the best quality image allocation without signal loss display.

• 1 HDMI in, 4 HDMI out
• HDMI 2.0, HDCP 2.2 compliant
• Output resolution up to 4096×2160@60
• Serializable to increase numbers of display

LED Video processor Appearance

LED Video processor Working Diagram

Parameter
Power
Input Voltage DC 12V

Enviroment
Temperature 0℃～55℃
Humidity 10%~95%

Physical
Weight: Nett 0.5 kg
Dimensions: Nett 231mmx98mmx24mm

Further Information:
RGBlink DXP H0104
RGBlink DXP H0104 LED Video Processor Specification
RGBlink DXP H0104 LED Video Processor User Manual
